Applications
The electronic boards of MIAB-CON burner control’s family are designed to manage gas appliances equipped with pneumatic premix burners and condensing heat exchanger.
They integrate all the features to manage LOW RANGE wall hung boilers.
If some extra functionalities are required, through a communication bus the functions can be improved using other external boards to manage External User Interfaces, Additional Input / Output etc…
The MIAB burner controls platform is a wide range of products that share the same mechanical features and which differ for the implemented functions: in this way it is possible to create different technical products while maintaining the same aesthetic.
MIAB-ATM Burner Control for Standard Efficiency Boiler – 230Vac Diverted Valve *
MIAB-ATM/ST Burner Control for Standard Efficiency Boiler– Unipolar Stepper Motor Diverted Valve *
MIAB-CON Burner Control for Pneumatic Condensing Boiler – 230Vac Diverted Valve
MIAB-CON/ST Burner Control for Pneumatic Condensing Boiler – Unipolar Stepper Motor Diverted Valve *
* Details reported in the corresponding detailed documentation
General Features
- Ignition & Safety control for pneumatic premixed Gas burners
- Heating comfort functions
- Domestic hot water comfort management
- Communication bus to interface with external accessories
- 230Vac diverted valve management
- Integrated User Interface with backlighted LCD display and 6 push buttons
- North American and Chinese Approval available on request
Accessories
The MIAB-CON family PCBs can be interfaced with the following
accessories:
- External User Interfaces: UI10, UI20, UI30 & UI40 platform devices
- Sistema di gestione delle zone FLEX
- External I/O expander: REL10 platform devices
- Remote control: ROAB platform devices
- Gateway to manage the PCB by smartphone: iModule v4 platform devices
- Outside temperature sensors: EXT10 series devices
- Contact temperature probes: TEM10 series devices
- Immersion temperature probes: IMM10 series devices
- Air Pressure switches: PRBHC series devices
- Plastic box housing: BOX10 & BOX20 series devices
- Rubber push buttons and keypad
- Wirings according to customer specification
Other burner controls products
MIAB-ATM
3Way – 230Vac, Controllo bruciatore, Efficienza standard, Entry Level, Modbus – External PCB option-
MIAB-ATM-ST
3Way – Stepper Motor, Controllo bruciatore, Efficienza standard, Entry Level, Modbus – External PCB option -
MIAB-CON
3Way – 230Vac, Condensazione - Pneumatica, Controllo bruciatore, Entry Level, Modbus – External PCB option -
MIAB-CON-ST
3Way – Stepper Motor, Condensazione - Pneumatica, Controllo bruciatore, Entry Level, Modbus – External PCB option -
BCN20
3Way – 230Vac, Condensazione - Pneumatica, Controllo bruciatore, Efficienza standard, Mid Range, Modbus – External PCB option -
BCS30
3Way – 230Vac, CH Safety Sensors, Condensazione - Pneumatica, Controllo bruciatore, Efficienza standard, High End, Lin – Integrated, Modbus – Integrated -
BCS30-ST
3Way – 230Vac, CH Safety Sensors, Condensazione - Pneumatica, Controllo bruciatore, Efficienza standard, High End, Lin – Integrated, Modbus – Integrated -
BCS30_EC
3Way – 230Vac, CH Safety Sensors, Condensazione - Pneumatica, Controllo bruciatore, Efficienza standard, High End, Lin – Integrated, Modbus – Integrated -
BCS30_EC-ST
3Way – 230Vac, CH Safety Sensors, Condensazione - Pneumatica, Controllo bruciatore, Efficienza standard, High End, Lin – Integrated, Modbus – Integrated
